CB Type Aligning Roller Bearings

CB type spherical roller bearings: a solid guarantee for mechanical operationIn various types of mechanical equipment, CB type spherical roller bearings play a key role and are important components to ensure the stable operation of the equipment.From a structural point of view, CB type spherical roller bearings are exquisitely constructed. It consists of an outer ring, an inner ring, two rows of symmetrical spherical rollers and a two-piece solid cage. The outer ring is equipped with a common spherical raceway, the inner ring has a middle rib, and small ribs on both sides. This structural design gives it good self-aligning performance. Even if the shaft is bent due to force or is installed non-concentrically, the bearing can still operate normally. The allowable alignment angle is generally between 1° and 2.5°, which effectively compensates for the concentricity error.In terms of load-bearing capacity, CB type spherical roller bearings perform well. It is mainly used to bear radial loa…
