Reinforced Sliding-Track Window Friction Stay

Window hardware · selection and application Reinforced Sliding-Track Window Friction Stay Several holes and formed features are visible along the track for product identification. Product form and connection details Application and fit Plan around the sliding-track envelope When reviewing this reinforced sliding-track stay, connect the component view to a section of the proposed window. Examine the track mounting face, the sliding path and the folded arm stack as separate areas; each occupies space that may be hidden in an overall sash view. Provide a close-up of the receiving surface under the track. Indicate the sliding direction and any obstruction near the track ends. Measure the closed gap available for the folded arm assembly. Profile coordination Treat this as window hardware rather than a furniture or window-seat hinge. Compare track features, end geometry and the position of the sliding block with the window system that will receive it. Confirm window type and pro…
