SINHO Flanged T Type Ceramic Lined Tee

Technical Specification   - Brand: SINHO - Lining: 92% /95% Alumina Ceramic (white) - Outer Pipe: Q235 carbon steel with black anti-corrosion paint, 304/316L stainless steel optional - Type: T shape tee (equal diameter / reducing tee optional) - Connection: Three flanged ends - DN Range: DN50~DN600, large diameter customized - Ceramic Thickness: 6~12mm, reinforced thickness at impact zone - Process: Interlocking tile pasted / SHS centrifugal - Flange Standard: GB, HG or custom drawing - Medium: Fly ash, coal powder, mine tailings, ore slurry, cement raw meal, solid-gas & solid-liquid mixture    Application Fields   Thermal power plant, mining, cement plant, metallurgy, coal chemical industry, abrasive slurry and powder conveying.   Part name Ceramic Tee External shell carbon steel Internal lining 92%/95% alumina corundum ceramics temperature -50℃—1000℃ color Silver/black, can be customized Application Specially resistant to particle erosion and wear, powder and pulp tr…
