Continuous Operation ITO 23BL07 Outer Rotor DC Motor

Continuous Operation ITO 23BL07 Outer Rotor DC Motor Product Overview Continuous Operation ITO 23BL07 Outer Rotor DC Motor is a compact External Rotor Motor manufactured by ITO MOTOR. This High Efficiency Motor can be configured as HVAC Motor and Fan Motor, featuring Direct Drive Motor design for reliable continuous operation. It is suitable for unmanned aerial vehicles, air pumps and model aircraft, delivering stable rotary power in compact limited installation space. Technical Specifications & Dimensional Details This ITO MOTOR External Rotor Motor model ITO-B023-001 works at rated voltage of 7.4 VDC, with operating temperature range of -25℃ to 40℃. The no-load speed reaches 10500 rpm with tolerance ±10%, and maximum no-load current is 0.5A. Rated speed is 9500 rpm ±10%, rated current maximum 7A and rated torque is 13 mN.m. The minimum stall current is 10A and minimum stall torque is 65 mN.m. Rotation direction supports CW or CCW. The maximum noise level is 80dBA, and rated s…
